BU115
Cat® Utility Brooms sweep and collect debris on smooth surfaces in forward or reverse travel. The Utility Broom is recommended for spoil removal during cold planing applications. The Utility Broom can be adjusted for greater bristle down-force in tough applications such as sweeping course material out of a cold planer cut.
Overall Width
71.3 in
Sweeping Width
59.4 in
Brush Diameter
26 in
DOWNLOAD TECHNICAL SPECIFICATIONS
Specification
Value
Overall Width
71.3 in
Sweeping Width
59.4 in
Brush Diameter
26 in
Required Hydraulics
Standard Flow
Height
31.2 in
Length
58.7 in
Weight
948 lb
Required Hydraulic Flow
30-83 L/min (8-22 gpm)
Optimal Hydraulic Pressure
145-227 bar (2100-3300 psi)
Motor Displacement
24 in³/rev
Brush Speed at Maximum Flow
190 rpm
Gutter Brush Weight
88.2 lb
Drive Method
Direct Drive
Ideal for cleaning and removing dirt, rock, snow and other debris from streets, parking lots, driveways, sidewalks and factory floors.
Utility Brooms have the ability to sweep and collect light debris on smooth surfaces in both forward or reverse.
Standard broom material is made of replaceable polypropylene and steel wire sections. Optional replacement brushes include all polypropylene and all steel wire.
Large hopper capacity allows greater productivity with longer sweeping cycles. Wide bucket opening with bolt-on, replaceable cutting edge permits fast, efficient dumping.
An optional water sprinkler kit is available which helps reduce the amount of airborne dust during your sweeping operations.
Rubber boots on front and sides of broom aid in containing debris and airborne contaminants during sweeping.
